Aatir Steel, a reputable manufacturer and supplier located in Cairo, Egypt, has built a solid reputation for delivering top-notch Carbon Steel A334 Grade 6 Tubing, designed to excel in both low-temperature and high-pressure settings. These tubes are crafted using cutting-edge technology and comply with rigorous international standards, guaranteeing exceptional strength, toughness, and precise dimensions. Aatir Steel’s commitment to quality, accuracy, and dependability has made it a go-to choice for a variety of industries. The company provides robust and efficient carbon steel tubing solutions not just across Egypt, but also on a global scale for essential industrial and mechanical applications.
The Carbon Steel A334 Grade 6 Tubing is mainly made up of carbon (with a maximum of 0.30%), manganese (ranging from 0.29% to 1.06%), along with phosphorus, sulfur, and silicon, resulting in a well-rounded chemical makeup. It boasts impressive mechanical properties, including high tensile and yield strength, outstanding impact toughness, and good ductility even at low temperatures. The tubing is designed for excellent weldability and machinability, ensuring reliable performance under pressure. Its fine-grained structure enhances its resistance to stress, thermal fatigue, and deformation, making it perfect for challenging engineering environments.
| Element | A/SA 334 Gr A6 |
| C | 0.30 max |
| Mn | 0.40-1.06 |
| P | 0.025 max |
| S | 0.025 max |
| Element | A/SA 334 |
| Tensile Strength, (MPa) | 380 min |
| Yield Strength, (MPa) | 205 min |
| Elongation min. % | 35 |
| Hardness, HB | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel A334 GR 6 Tubing in Cairo, Egypt. We provide premium steel materials and a comprehensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our vast inventory includes Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Committed to fast delivery and exceptional customer service, we source only the highest-grade raw materials to ensure superior strength and durability for demanding industrial applications. Reach out to us today for all your Carbon Steel A334 GR 6 Tubing requirements!
| Outside | Nominal | Wall | Inside | Weight |
| Diameter | Pipe Diameter | Thickness | Diameter | Lbs |
| Inches | Inches | Inches | Inches | Per Foot |
| 1.660 | 1-1/4 | .140 | 1.380 | 2.273 |
| 1.315 | 1 | .133 | 1.049 | 1.679 |
| 1.900 | 1-1/2 | .145 | 1.610 | 2.718 |
| 2.875 | 2-1/2 | .203 | 2.469 | 5.793 |
| 2.375 | 2 | .154 | 2.067 | 3.653 |
| 6.625 | 6 | .28 | 6.056 | 18.97 |
| 3.50 | 3 | .216 | 3.068 | 7.576 |
| 4.50 | 4 | .237 | 4.026 | 10.79 |
| 4 | 3-1/2 | .226 | 3.548 | 9.109 |
| 5.563 | 5 | .258 | 5.047 | 14.62 |
| 8.625 | 8 | .322 | 7.981 | 28.55 |
You’ll find Carbon Steel A334 Grade 6 Tubing widely utilized in sectors like power generation, petrochemicals, oil and gas, and refrigeration. It’s particularly suited for heat exchangers, pressure vessels, condensers, and piping systems that operate in low-temperature conditions. These tubes are also essential in refineries, cryogenic plants, and boiler systems, thanks to their impressive toughness and ability to endure extreme thermal conditions. With their superior weldability, resistance to corrosion, and long-lasting service life, they are the preferred choice for transporting fluids and facilitating heat transfer in critical operational settings.
