Aatir Steel, based in Cairo, Egypt, has built a solid reputation as a reliable manufacturer and supplier of SA 516 GR.60N NACE and HIC Plates. Known for their commitment to quality and dependability, Aatir Steel caters to essential industries like oil & gas, petrochemical, and energy, both locally and internationally. The company specializes in producing steel plates that adhere to strict industry standards, particularly for performance in sour service environments. With cutting-edge manufacturing techniques and a talented technical team, Aatir Steel guarantees that each product boasts outstanding strength, corrosion resistance, and compliance with NACE specifications, making them a trusted partner for challenging industrial applications.
SA 516 GR.60N NACE and HIC Plates are carbon steel pressure vessel plates specifically designed to resist hydrogen-induced cracking (HIC) and sulfide stress corrosion in sour service conditions. Their typical composition features carbon (max 0.21%), manganese (0.55–0.98%), phosphorus (max 0.035%), and sulfur (max 0.035%). These plates are supplied in a normalized state to boost toughness and ductility. Mechanically, they provide a minimum tensile strength of 415–550 MPa and a yield strength of at least 240 MPa. These characteristics, along with compliance in HIC testing, make them perfect for high-pressure, corrosive environments.
| Grade | ASME SA 516 GR.60N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.20 | 0.4 | 0.95/1.50 | 0.025 | 0.025 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength | Yield strength | Elongation min, % 200 mm (8 in) | Elongation min, % 50 mm (2 in) |
| 415-550 MPa | 250 MPa | 21 | 25 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-161-430A | EN10028 P265GH | A/SA516 – Grade 60 | DIN 17155 HII |
SA 516 GR.60N NACE and HIC Plates find extensive use in oil and gas applications where resistance to hydrogen-induced cracking and sour gas corrosion is crucial. They are particularly suited for building pressure vessels, storage tanks, separators, and heat exchangers that operate under severe chemical and environmental conditions. Additionally, they are employed in refineries, offshore rigs, petrochemical plants, and pipeline systems. With excellent weldability, toughness, and resistance to brittle fracture, these plates are a top choice for demanding applications.
SA516 GR.60N NACE and HIC Plates are engineered to be used in pressure vessels, storage tanks, and heat exchangers where the resistance to hydrogen-induced cracking is required. These plates are widely used in oil and gas, petrochemical, chemical processing and power industries. Where sour gas conditions and corrosive atmospheres pose a risk. Their excellent mechanical properties and NACE and HIC compliance make them suitable for use at high-pressure and high-temperature in offshore platforms, refineries, and industrial plants.
