Aatir Steel, a prominent manufacturer and supplier located in Cairo, Egypt, is dedicated to crafting top-notch Carbon Steel JIS G3445 Pipes that adhere to rigorous Japanese Industrial Standards. These pipes are designed specifically for mechanical and automotive applications that demand exceptional strength, precise dimensions, and durability. Utilizing advanced seamless and welded techniques, Aatir Steel ensures that their JIS G3445 Pipes feature consistent wall thickness and smooth internal surfaces. Renowned for their outstanding machinability, longevity, and pressure resistance, Aatir Steel delivers reliable and cost-effective carbon steel solutions tailored to the needs of engineering, automotive, and industrial equipment manufacturers throughout Egypt.
The Carbon Steel JIS G3445 Pipes are primarily composed of iron, with a carefully controlled carbon content ranging from 0.15% to 0.30%, along with manganese (0.30% to 1.20%) and trace amounts of silicon, sulfur, and phosphorus. This specific chemical makeup boosts hardness, tensile strength, and machinability. The mechanical properties showcase a tensile strength of 400 to 580 MPa and a yield strength of 245 to 355 MPa, ensuring remarkable resistance to deformation and wear. Additionally, these pipes offer good elongation (≥15%) and toughness, making them perfect for cold drawing, bending, and welding in high-performance mechanical and structural applications.
| Standard | : | JIS G3445 |
| Description Name | : | STKM 11A Steel tube, STKM 12A steel tubes, STKM 12C steel tubes, STKM 13A steel tubes, STKM 13C steel tubes |
| Size | : | 6mm-340mm |
| Wall Thickness | : | 1mm-50mm |
| Shape | : | Round |
| Production Type | : | Cold drawn, cold rolled or hot rolled |
| Length | : | Single random length/ Double random length or as customer’s actual request max length is 10m |
| Grade | : | STKM 11A, STKM 12A, STKM 12C, STKM 12B, STKM 13A, STKM 13B, STKM 13C, STKM 15A, STKM 17A |
| C | Si | Mn | P | S |
| max 0.12 | max 0.35 | max 0.6 | max 0.04 | max 0.04 |
| Assortment | Yield point or Proof stress | Tensile strength | Elongation | Reduction of area | Charpy impact strength |
| – | N/mm 2 | N/mm 2 | % | % | J/cm 2 |
| Tubes | 290 | 35 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Jaxon Steel is a trusted manufacturer and supplier of high-quality Carbon Steel JIS G3445 Pipe products in Cairo, Egypt. Specializing in premium steel materials, we offer a diverse range of products, including Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our extensive inventory features Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. With a strong commitment to timely delivery and exceptional customer service, Jaxon Steel ensures the supply of top-grade materials that deliver superior performance in various industrial applications. Trust Jaxon Steel for all your Carbon Steel JIS G3445 Pipe needs.
| Permissible Specified Outside Diameter and Specified Wall Thickness | ||
| Specified Outside Diameter D mm (in.) | Specified Wall Thickness t mm (in.) | |
| Special Light Sizes a | Regular Sizes | |
| ≥ 10.3 (0.405) to < 13.7 (0.540) | — | ≥ 1.7 (0.068) to ≤ 2.4 (0.094) |
| ≥ 13.7 (0.540) to < 17.1 (0.675) | — | ≥ 2.2 (0.088) to ≤ 3.0 (0.118) |
| ≥ 17.1 (0.675) to < 21.3 (0.840) | — | ≥ 2.3 (0.091) to ≤ 3.2 (0.125) |
| ≥ 21.3 (0.840) to < 26.7 (1.050) | — | ≥ 2.1 (0.083) to ≤ 7.5 (0.294) |
| ≥ 26.7 (1.050) to < 33.4 (1.315) | — | ≥ 2.1 (0.083) to ≤ 7.8 (0.308) |
| ≥ 33.4 (1.315) to < 48.3 (1.900) | — | ≥ 2.1 (0.083) to ≤ 10.0 (0.394) |
| ≥ 48.3 (1.900) to < 60.3 (2.375) | — | ≥ 2.1 (0.083) to ≤ 12.5 (0.492) |
| ≥ 60.3 (2.375) to < 73.0 (2.875) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 14.2 (0.559) |
| ≥ 73.0 (2.875) to < 88.9 (3.500) | ≥ 2.1 (0.083) to ≤ 3.6 (0.141) | > 3.6 (0.141) to ≤ 20.0 (0.787) |
| ≥ 88.9 (3.500) to < 101.6 (4.000) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 22.0 (0.866) |
| ≥ 101.6 (4.000) to < 168.3 (6.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 25.0 (0.984) |
| ≥ 168.3 (6.625) to < 219.1 (8.625) | ≥ 2.1 (0.083) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 219.1 (8.625) to < 273.1 (10.750) | ≥ 3.2 (0.125) to ≤ 4.0 (0.156) | > 4.0 (0.156) to ≤ 40.0 (1.575) |
| ≥ 273.1 (10.750) to < 323.9 (12.750) | ≥ 3.6 (0.141) to ≤ 5.2 (0.203) | > 5.2 (0.203) to ≤ 45.0 (1.771) |
| ≥ 323.9 (12.750) to < 355.6 (14.000) | ≥ 4.0 (0.156) to ≤ 5.6 (0.219) | > 5.6 (0.219) to ≤ 45.0 (1.771) |
| ≥ 355.6 (14.000) to < 457 (18.000) | ≥ 4.5 (0.177) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 457 (18.000) to < 559 (22.000) | ≥ 4.8 (0.188) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 559 (22.000) to < 711 (28.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 45.0 (1.771) |
| ≥ 711 (28.000) to < 864 (34.000) | ≥ 5.6 (0.219) to ≤ 7.1 (0.281) | > 7.1 (0.281) to ≤ 52.0 (2.050) |
| ≥ 864 (34.000) to < 965 (38.000) | — | ≥ 5.6 (0.219) to ≤ 52.0 (2.050) |
| ≥ 965 (38.000) to < 1422 (56.000) | — | ≥ 6.4 (0.250) to ≤ 52.0 (2.050) |
| ≥ 1422 (56.000) to < 1829 (72.000) | — | ≥ 9.5 (0.375) to ≤ 52.0 (2.050) |
| ≥ 1829 (72.000) to < 2134 (84.000) | — | ≥ 10.3 (0.406) to ≤ 52.0 (2.050) |
Aatir Steel’s Carbon Steel JIS G3445 Pipes find extensive applications in mechanical structures, automotive parts, and industrial machinery. Their strength and precision make them ideal for crafting shafts, axles, steering components, drive shafts, and structural supports. In the automotive industry, these pipes are utilized in chassis, suspension systems, and engine parts. Their capacity to endure high stress and pressure also renders them suitable for hydraulic piping, conveyor systems, and manufacturing equipment. Aatir Steel’s JIS G3445 Pipes promise long-lasting performance, excelling in various demanding applications.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
