Aatir Steel, Egypt, Cairo, is a prominent producer and distributor of EN 9 plates and sheets recognized for providing quality carbon steel products to fulfill the varied requirements of the engineering and industrial markets. With an emphasis on performance, reliability, and accuracy, Aatir Steel ensures that all EN 9 plates and sheets adhere to rigorous quality standards. The organization services a broad spectrum of industries, ranging from automotive to general engineering, with steel solutions that deliver strength along with machinability. With state-of-the-art production methods and customer-driven service, Aatir Steel remains a trusted ally for carbon steel needs.
EN 9 sheets and plates are produced from medium carbon steel containing a typical chemical content of 0.50–0.60% carbon, 0.60–0.90% manganese, and minimal contents of silicon, sulfur, and phosphorus. This alloy has a good combination of hardness and strength with modest ductility. EN 9 has tensile strength ranging from 600–800 MPa and can be enhanced further through processes like hardening and tempering. EN 9’s mechanical properties make it appropriate for use in applications that demand high surface hardness, wear resistance, and strength with maintenance of machinability.
Grade : EN9 Low Alloy Steel Plate
Thickness : from 3mm up to as thick as 150mm
Length :3000mm-18000mm
Supply Condition : As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement.
Impact tested : -52° C
Process of Manufacturing : Hot-Rolled (HR)
| Grade | Cr | C | Ni | Si | S | Mn | P | Mo |
| EN – 9 | – | .50 – .60 | – | .05 – .35 | .040 MAX | .50 – .80 | .040 MAX | – |
| Heat Treatment | Condition Tons/SQ.inch | Tensile Stress RE MPA | RP0.2 MPA | A min on 5.65so | Impac | Hardness HB | Limited Ruling Section mm | |
| IZODFT.L.b | KCV Joules | |||||||
| Normalise | 45 | 700 | – | 12 | – | – | 201-255 | 63 |
| 39 | 600 | – | 13 | – | – | 170/223 | 250 | |
| R | 45/55 | 700/850 | 385 | 14 | – | – | 201/277 | 100 |
| S | 50/60 | 775/925 | 450 | 14 | – | – | 223/277 | 63 |
| T | 55/65 | 850/1000 | 555 | 12 | – | – | 248/302 | 19 |
| BS 970 1991 | BS 970 1955 EN | AISI/SAE | Werkstoff |
| 070M55 | EN9 | 1055 | 1.0535 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
EN 9 plates and sheets are used extensively in the manufacture of parts that need to be highly surface-hardened and wear-resistant. In automobile manufacturing, they are employed in the production of shafts, gears, sprockets, and crankshafts. In overall engineering, EN 9 can be used for machine components, spindles, keys, and tooling that experience moderate to severe wear. The plates are also employed in farm equipment, construction machinery, and transmission power components. Their heat-treatability to greater strength and toughness make EN 9 a perfect material for precision components requiring toughness along with wear resistance.
